42CrMo Cement Nickel Ore Quick Lime Kiln Parts
From the wet process to dry process, from size around 2 meters to 6 meters.from cement plant other industry filed. From two piers to four piers.Now our rotary kiln are the leaders for rotary kiln in cement plant with capacity from 300tpd,700tpd,800tpd,1000tpd,1200tpd,1500tpd,2000tpd,2500tpd,3000tpd,3500tpd,4000tpd,5000tpd, 8000tpd ,lime plant capacity from 300tpd to 1200tpd.300tpd,400tpd,600tpd,800tpd,1000tpd,1200tpd.
Nickel ore plant from 50000tons 150000tons.our such rotary kiln with advanced technology and high automation level can increase the running rate 3-5%,production has been raised by 5-10%, and heat consumption has been reduced 15% down. Till now we have sold to more than 200 hundred clients in the domestic clients in such filed and more than 100 hundred clients in foreign countries.
| No. | Item | Technical data and performance |
| 1 | Size | Φ2.5×45m |
| 2 | Capacity | kg/h |
| 3 | Quality | China national standard |
| 4 | Slope | 3.5% |
| 5 | Shell speed | 0.4～ 1.2r/min |
| 6 | Auxiliary speed | 0.2rpm |
| 7 | Supporting piers | 3 piers |
| 8 | Sealing at kiln outlet | Spring steel plate |
| 9 | Cooling way of kiln outlet | Air cooling |
| 10 | Sealing at kiln inlet | Spring steel plate |
| 11 | Drive type | Single drive |
| 12 | Thrust roller type | Hydraulic thrust roller |
| 13 | Main motor type | YVF2-280M-6,P=55KW, Rated speed 1000r/min |
| 14 | Main gear box | ZSY315-40 |
| 15 | Auxiliary motor type | Y160M-6,7.5KW,Rated speed 970r/min |
| 16 | Auxiliary gear box | ZL35-7,speed ratio14 |
| 17 | Inlet temperature of medium | 1000~1100℃ |
| 18 | Outlet temperature of medium | 350~400℃ |
| 19 | Equipment weight | 158t |
| 20 | Running rate | 98% |
